Chillers FMEA Reference Guide for Reliability Teams
Every significant chiller failure mode — compressor, evaporator, condenser, refrigerant loop, oil system, controls — with severity/occurrence/detection scoring, RPN, root cause, and RCM-recommended task. Anchored to ASHRAE Project 1043-rp canonical fault set, Fuzzy-FMEA field research on 31 real chiller stations, and industry-standard S×O×D scoring.
-
7
canonical chiller fault categories (ASHRAE Project 1043-rp)
-
$20–30K
annual electricity cost of 10% kW/ton efficiency loss on a 500-ton chiller
-
1°F / 1–2%
approach-temperature drift per efficiency loss — tube fouling signature
-
Weeks
early warning from vibration spectrum trending before mechanical failure
The Scoring Framework
How RPN Is Calculated — the Working Method
Every failure mode in this reference is scored using the industry-standard Risk Priority Number formula: RPN = Severity × Occurrence × Detection. Each factor is rated on a 1–10 scale. The higher the RPN, the higher the maintenance priority. Below are the working rating anchors so scores are defensible across FMEA workshops and reviews.
Consequence of the Failure
- 1–2 · No noticeable effect, minor inefficiency
- 3–4 · Reduced capacity, higher energy cost
- 5–6 · Partial loss of cooling, occupant discomfort
- 7–8 · Full loss of cooling, regulated-space impact
- 9–10 · Safety event, refrigerant release, catastrophic damage
Likelihood of the Failure Mode
- 1–2 · Rare — no history in the fleet
- 3–4 · Occasional — 1 event in 5+ years per asset
- 5–6 · Moderate — annual event across the fleet
- 7–8 · Frequent — multiple events per year
- 9–10 · Certain — occurs on every asset routinely
Likelihood of Catching Before Failure
- 1–2 · Certain — continuous condition monitoring in place
- 3–4 · High — routine inspection catches it reliably
- 5–6 · Moderate — visible on periodic PM checks
- 7–8 · Low — only caught with specialised testing
- 9–10 · None — failure is the first indication
The Complete Reference
Chiller FMEA Worksheet — 20 Priority Failure Modes
This is the working reference. Twenty priority failure modes, organised by subsystem, with severity, occurrence, and detection scores giving the RPN — plus the RCM-selected task per mode. Higher RPN sits at the top of the maintenance queue. Values reflect typical commercial chiller operation; calibrate to your specific fleet failure history.
| Subsystem | Failure Mode | Root Cause | S | O | D | RPN | RCM Task |
|---|---|---|---|---|---|---|---|
| Compressor | Chiller surging | Low load, high lift, IGV mis-position | 8 | 5 | 4 | 160 | Continuous surge monitoring, IGV calibration |
| Compressor | Bearing wear / spalling | Fatigue, lubrication breakdown | 9 | 4 | 4 | 144 | Vibration spectrum analysis quarterly |
| Oil System | Oil overheating (>120°C) | Condenser fouling, low voltage, low oil | 8 | 4 | 4 | 128 | Oil temperature trend, oil analysis quarterly |
| Refrigerant | Refrigerant leak | Seal failure, fitting corrosion, tube crack | 8 | 5 | 3 | 120 | Annual leak test, EPA 608 compliance, purge log |
| Condenser | Condenser tube fouling | Poor water treatment, scale build-up | 6 | 7 | 3 | 126 | Approach temperature trend, annual tube brush |
| Compressor | Abnormal sound / vibration | Bearing, impeller imbalance, foreign object | 7 | 5 | 3 | 105 | Vibration FFT monthly, acoustic monitoring |
| Refrigerant | Non-condensable gas in refrigerant | Air ingress through leaks, improper service | 6 | 6 | 3 | 108 | Purge unit runtime log, condensing pressure trend |
| Evaporator | Reduced chilled water flow | Strainer blockage, pump degradation, air-lock | 7 | 4 | 3 | 84 | Flow monitoring, strainer inspection quarterly |
| Condenser | Reduced condenser water flow | Cooling tower fouling, pump fault | 6 | 4 | 3 | 72 | Flow trend, tower fill inspection annually |
| Controls | Temperature sensor drift | Sensor aging, calibration loss | 5 | 6 | 4 | 120 | Annual calibration against reference standard |
| Refrigerant | Refrigerant overcharge | Improper service, guess-charge practice | 5 | 5 | 4 | 100 | Weighed-charge verification at service, superheat check |
| Oil System | Excess oil in refrigerant loop | Oil separator carryover, high migration | 5 | 4 | 5 | 100 | Oil sight-glass check, separator diff-pressure trend |
| Evaporator | Evaporator tube freeze | Low flow, low refrigerant, EXV fault | 9 | 2 | 5 | 90 | Freeze protection setpoint verify, flow interlock test |
| Compressor | Motor winding insulation degradation | Thermal cycling, moisture ingress | 9 | 3 | 4 | 108 | Annual meg-ohm test, insulation resistance trend |
| Controls | Flow switch failure | Contact wear, contamination, wiring | 8 | 3 | 4 | 96 | Quarterly flow-switch functional test |
| Refrigerant | Expansion valve mis-tuning | Bulb charge loss, orifice contamination | 5 | 4 | 4 | 80 | Superheat verification each PM cycle |
| Compressor | Short-cycling (1–3 min intervals) | Low buffer volume, refrigerant leak, control drift | 7 | 3 | 3 | 63 | Runtime log review, buffer tank sizing check |
| Controls | VFD parameter drift | Firmware issue, parameter overwrite | 5 | 3 | 4 | 60 | Annual VFD parameter backup and verify |
| Structure | Anchor / vibration isolator wear | Corrosion, elastomer degradation | 4 | 4 | 3 | 48 | Annual visual inspection, isolator torque check |
| Oil System | Oil filter clog | Contamination, extended service interval | 4 | 4 | 3 | 48 | Oil filter diff-pressure alarm, scheduled change-out |
How to read this: Modes with RPN ≥ 100 (navy-highlighted) go into the priority queue for condition monitoring and predictive intervention. Modes 60–99 (amber-highlighted) get scheduled inspection with trend-triggered action. Modes below 60 (soft-navy) get standard periodic PM with failure-finding tasks on hidden functions.
Subsystem Breakdown
FMEA by Chiller Subsystem — Where the Risk Actually Sits
Aggregating RPN by subsystem reveals where the maintenance dollar earns its highest return. Compressor and refrigerant loop routinely dominate — together representing more than half of aggregate chiller risk on centrifugal machines — with oil system, controls, and heat exchangers rounding out the profile.
Highest Aggregate RPN
Surging, bearing wear, motor winding, short-cycling, sound/vibration. Vibration spectrum trending and IGV calibration are the highest-return interventions. Weeks of P-F lead time available on bearing modes.
Regulatory + Environmental Exposure
Leaks, overcharge, non-condensable gas, EXV drift. EPA 608 compliance mandatory; purge unit runtime log and superheat verification are the operational levers.
The Efficiency Money Pit
Condenser and evaporator tube fouling. 1°F approach drift equals 1–2% efficiency loss. Approach-temperature trending catches fouling weeks before it starts costing serious kW/ton.
Compressor Life Determinant
Oil overheating, excess oil migration, filter clog. Quarterly oil analysis and separator differential pressure trending are the two-thirds coverage for compressor life extension.
Silent Efficiency Drift
Temperature sensor drift, flow switch failure, VFD parameter loss. Annual calibration and functional testing prevent the "chiller is running fine but the numbers are all wrong" failure mode.
Low RPN, Non-Zero Impact
Anchor wear, vibration isolator degradation. Low occurrence but annual visual inspection retained because the failure-finding task is cheap and the consequence of cascade failure is not.
The Economic Case
10% kW/ton Efficiency Loss = $20–30K per Year on a 500-Ton Chiller
Chiller PM is the one maintenance programme in a facility where cutting corners always shows up in the energy bill before it shows up as a breakdown. Approach-temperature drift, IGV mis-calibration, refrigerant charge error, and sensor drift each cost more in electricity in one year than the FMEA-driven PM programme costs to run for three. Oxmaint operationalises the entire chiller FMEA reference — RPN scoring per asset, condition-monitoring intervals per mode, and mobile work orders with the right refrigerant, torque, and calibration specs per chiller family.
Task Selection Decision Path
How the RPN Score Translates Into a Maintenance Task
RPN is a prioritisation tool, not the maintenance strategy itself. The strategy is selected using RCM decision logic — safety consequence, technical feasibility, cost-effectiveness, and the P-F interval available. Below is the working task-selection path applied to chiller failure modes.
-
01
Safety or Environmental Consequence?
If yes (refrigerant release, catastrophic pressure event, fire risk), task must be feasible and effective regardless of cost. Failure-finding retained on all hidden functions.
-
02
Is Condition Monitoring Technically Feasible?
If a detectable P-F interval exists and monitoring technology is available (vibration FFT, approach temperature, oil analysis), on-condition task is the default choice.
-
03
Is the Failure Age-Related?
If wear-out pattern documented (Nowlan-Heap Patterns A/B/C — rare in complex chiller subsystems), fixed-interval time or usage-based PM at end of useful life.
-
04
Hidden Function?
Flow switches, freeze protection interlocks, refrigerant relief valves — failure only reveals itself when the primary function fails. Failure-finding task scheduled at less than half the mean-time-to-failure.
-
05
No Cost-Effective Task Available?
Redesign consideration (dual-pump, N+1 chiller, redundant sensor). Run-to-failure accepted only on low-RPN modes with adequate sparing and no cascade consequence.
Built for Reliability Teams
How Oxmaint Runs the Chiller FMEA End to End
-
Live FMEA per Asset
RPN Scored and Updated on Every Event
Every chiller in the register carries its own live FMEA. Occurrence scores update automatically as work-order history accumulates; RPN recalculates and reprioritises the maintenance queue.
-
Condition Monitoring
Vibration, Approach Temp, Oil Analysis
IoT sensors and manual sample results flow into the same asset record. Approach temperature, vibration spectrum, and oil analysis all trend against the P-F thresholds documented per mode.
-
Auto Work Orders
Trigger on Threshold, Not Calendar
Condition-based work orders fire when trend data crosses P-detection thresholds — 1°F approach drift, vibration signature shift, oil metal-particle count spike. Fewer PMs, better catches.
-
EPA 608 Refrigerant Tracking
Leak Rate, Recovery, Purge Log
Purge runtime, leak-test dates, refrigerant recovery quantities, and technician certification all tracked at the asset level — audit-ready EPA 608 compliance without spreadsheets.
-
Mobile Execution
Right Charge Weight, Torque, PPE In-Hand
Technicians receive work orders with refrigerant type and weighed-charge target per chiller model, torque specs, and PPE requirements. Photo history from the last three services attached.
-
Reliability Reporting
RPN Trend, kW/ton Baseline Deviation
Facility manager and reliability director dashboards show RPN aggregate trend per chiller, efficiency drift from commissioning baseline, and cost-of-drift converted to annual electricity impact.
Measured Outcomes
What Reliability Teams Report Using This FMEA Reference
-
10%+
kW/ton Efficiency Recovered
Teams tracking approach temperature and acting on 1°F drift routinely recover 10% or more of commissioning kW/ton baseline — $20–30K per year on a 500-ton chiller.
-
Weeks
Bearing Failure Prevented
Vibration spectrum trending on centrifugal compressors detects bearing wear, impeller fouling, and refrigerant flooding weeks before mechanical failure.
-
EPA 608
Compliance Audit-Ready
Leak-test dates, refrigerant recovery quantities, purge runtime, and technician certification tracked per asset — full compliance record produced in seconds.
-
$0
Free Forever Plan to Start
Cloud-based, mobile-first. Load this FMEA reference into one chiller asset today, run RPN scoring on your fleet, and scale to the full facility when the reliability gain is proven.
Frequently Asked
Chiller FMEA Questions
Where does the seven-fault ASHRAE 1043-rp reference come from?
ASHRAE Project 1043-rp is the canonical experimental study on centrifugal chiller faults, conducted on a McQuay PEH048J 90-ton chiller with faults artificially induced at four severity levels each. The seven categories — reduced condenser water flow, non-condensable gas, condenser fouling, reduced evaporator water flow, excess oil, refrigerant overcharge, and refrigerant leak — are the reference set every serious chiller reliability programme benchmarks against. Start free and load the ASHRAE seven-fault set into your chiller register today.
Should we adjust the RPN scores for our specific facility?
Yes — always. The values in this reference reflect typical commercial chiller operation. Occurrence in particular should be calibrated to your actual fleet failure history over the last 3–5 years. Severity should reflect your specific consequence categories (data centre uptime is a different severity than a school gym). Detection reflects the monitoring technology you have deployed. Recalibrate quarterly as data accumulates.
Does this apply to screw and absorption chillers, or only centrifugal?
The core failure modes — refrigerant loop, heat exchanger fouling, controls, oil system — apply across all chiller types. Compressor-specific modes differ: centrifugal machines get surge and IGV modes; screw chillers get rotor profile wear and slide-valve modes; absorption units get concentrator and generator modes with lithium bromide chemistry. Use this reference as the base and layer type-specific compressor modes for your fleet mix. Book a demo to see chiller-type-specific FMEA templates.
How does approach temperature trending catch fouling?
Approach temperature is the difference between the refrigerant saturation temperature and the leaving-water temperature in the condenser or evaporator. As tube surfaces foul, heat-transfer efficiency drops, and the approach temperature drifts up. A 1°F drift corresponds to a 1–2% kW/ton efficiency loss. Trending this metric weekly catches fouling weeks before the plant operator notices increased power consumption.
Is there a free plan to run this FMEA on one chiller first?
Yes. Oxmaint offers a free forever plan — enough to load this FMEA reference into one chiller, connect condition-monitoring data, calibrate RPN to your facility's history, and prove the reliability and efficiency gains before rolling out to the full plant. Cloud-based, mobile-first — no server procurement or infrastructure commitment. Sign up for the free plan and stand up chiller FMEA on one asset today.
Score · Prioritise · Monitor · Act
FMEA Is Not a Workshop Deliverable. It Is a Live Operating Document.
Twenty failure modes, ranked by RPN, mapped to root cause and RCM-selected task — that is the working chiller reliability programme. Anchored to ASHRAE Project 1043-rp, calibrated to your fleet history, and updated every time a work order closes with a root cause tag. Oxmaint runs the entire cycle: live FMEA per asset, condition monitoring against P-F thresholds, mobile execution with the right specs, and reporting that converts efficiency drift into annual electricity cost.
