EAF Hydraulic System Maintenance Checklist
A circuit-by-circuit inspection framework for electric arc furnace hydraulics, built for steel plant maintenance teams who need leaks, pressure drift and contamination caught during routine checks instead of during a heat.
10Inspection Categories
52Check Points
6Frequency Levels
01Power UnitReservoir, pumps, motors, standby pump
02ConditioningFilters, cooler, fluid sampling
03Energy StorageAccumulators and safety blocks
04Control ValvesProportional, servo, directional, relief
05ActuatorsCylinders, hoses, rod ends, sensors
EAF Hydraulic Inspection Checklist by Category
Work through the categories in order, tick each item, and record any exception as a work order. Intervals are a starting point, so adjust them to furnace duty, fluid type and OEM guidance.
SEvery shiftWWeeklyMMonthlyQQuarterlyAAnnual or outageEEach job or event
01Shift-Start Handover Check
Review the previous shift log for hydraulic alarms, oil top-ups and open leaks before the furnace is charged, so known issues are not rediscovered mid-heat.SShift · Operator
Confirm the duty pump is running, the standby pump is available and the HMI shows no active hydraulic alarms.SShift · Operator
Compare standby system pressure with the last shift reading and the normal band, and log both numbers.SShift · Operator
Walk the platform for fresh oil, wet hoses or drips under the roof lift, tilt cylinders and electrode arms.SShift · Operator
Verify cooling water flow indication and oil temperature are inside the operating band before charging begins.SShift · Operator
Cycle roof lift and swing, slag door and electrode arms at no load and watch for jerky motion, delay or drift.SShift · Operator
02Power Unit and Reservoir
Read reservoir level at the sight glass under normal operating conditions. A level that falls between checks signals an external leak or cylinder seal bypass rather than normal consumption.SShift · Operator
Compare oil temperature with the OEM band at a similar load point each shift. A rising baseline at the same duty points to cooler fouling, internal leakage or relief valve drift.SShift · Operator
Inspect the reservoir breather and air filter for dust loading. A blocked breather pulls unfiltered bay dust past seals and through fill points.WWeekly · Maintenance technician
Check tank seams, return diffusers and drain plugs for weeping, and keep the tank top clean of scale so a fresh leak is visible.WWeekly · Maintenance technician
Take an oil sample from a consistent live-zone port and log particle count, water content and viscosity against the cleanliness target set by the component supplier.MMonthly · Reliability technician
03Pumps, Motors and Couplings
Listen for pump noise changes at standby and under load. Cavitation sounds like gravel and usually traces to a restricted suction line, low oil level or cold, thick oil.SShift · Operator
Check case drain flow or case temperature on axial piston pumps. A rising trend is one of the earliest signs of internal wear.WWeekly · Reliability technician
Inspect coupling elements, guards and alignment, and log motor vibration and bearing temperature at the same point each time.MMonthly · Mechanical technician
Record discharge pressure at standby and at peak demand during roof swing or tilt, so recovery speed can be compared across weeks.WWeekly · Reliability technician
Test duty and standby pump changeover so the backup pump is proven to start and build pressure before it is needed.QQuarterly · Maintenance supervisor
04Filtration and Fluid Condition
Read filter differential pressure indicators with oil at operating temperature. Cold oil can give a false high reading, and a reading that jumps quickly after a change suggests heavy ingression.WWeekly · Maintenance technician
Change pressure, return and kidney-loop elements by condition and by calendar, and keep matching spare elements in stock.MMonthly · Maintenance technician
Verify the fluid type at every top-up against the nameplate. Do not mix fire-resistant fluid families without written OEM or supplier approval.EEach top-up · Technician
Check water content, and for water-glycol systems confirm the water ratio stays in the specified range.MMonthly · Reliability technician
Confirm fill and sampling points are capped and labelled, and that transfer containers and funnels are clean and covered.WWeekly · Lubrication technician
05Valves and Control
Compare electrode valve command with cylinder position feedback. Growing lag, hunting or null drift is an early indicator of contamination or valve wear.WWeekly · Automation technician
Inspect solenoid coils and connectors for heat discoloration, moisture and loose pins, because failures near the shell often start at the connector.MMonthly · Electrical technician
Verify relief and reducing valve settings against the design sheet and confirm tamper seals are intact.QQuarterly · Reliability technician
Check valve stand sub-plates and manifold joints for external leakage and confirm mounting bolt torque has not relaxed.MMonthly · Mechanical technician
Inspect and replace pilot and servo valve filters per OEM guidance, since valve sticking often starts at a clogged pilot screen.QQuarterly · Automation technician
06Cylinders, Rods and Seals
Inspect rod surfaces for scoring, pitting and slag spatter, and confirm wipers are intact. Damaged rods destroy new seals within days.WWeekly · Mechanical technician
Run a drift test with the roof held or electrode positioned, and record position loss over a fixed time so seal bypass is trended, not guessed.MMonthly · Reliability technician
Grade rod seal weep as a light film, a visible drip or a continuous leak, and record the grade so escalation is consistent between shifts.WWeekly · Maintenance technician
Inspect clevis pins, spherical bearings, mounts and fasteners for wear, cracks and missing lubrication, particularly on electrode arm and roof cylinders.MMonthly · Mechanical technician
Check position transducer housings, cables and heat shielding for damage that would corrupt feedback to the electrode regulator.MMonthly · Automation technician
07Hoses, Piping and Fire Protection
Inspect hoses on moving arms and near the shell for abrasion, hardened or blistered covers and leaking fittings, and check date codes against the replacement policy.WWeekly · Maintenance technician
Confirm heat shields, hose sleeves and fire-resistant wraps are present and have not been displaced during earlier repairs.WWeekly · Maintenance technician
Check rigid pipe clamps, supports and tube fittings for vibration cracking and looseness, especially near pulsating pump outlets.MMonthly · Mechanical technician
Clear oil accumulation from platforms, cable trays and surfaces near hot zones, and record where it came from so the leak is fixed and not just wiped.SShift · Operator
Test hydraulic power unit emergency stop, local shutoff and any detection or suppression interlocks according to the site fire protection plan.QQuarterly · Safety and maintenance
08Accumulators and Cooling
Check accumulator precharge against the nameplate value, only after hydraulic pressure is fully released and the work is isolated under the plant lockout procedure.QQuarterly · Certified technician
Inspect accumulator safety blocks, mounts and relief devices, and record any pressure sag after shutdown that suggests precharge loss.QQuarterly · Certified technician
Compare cooler inlet and outlet temperatures for oil and water. A shrinking temperature difference indicates fouling, restricted flow or a failing exchanger.WWeekly · Maintenance technician
Clean cooling water strainers and check water quality, because scale and debris reduce heat transfer long before an alarm appears.MMonthly · Utilities technician
Test oil temperature switches, level switches and high-temperature alarms so protective trips are proven and not assumed.QQuarterly · Automation technician
09Planned Outage Deep-Dive Checks
Replace hoses reaching their age limit under the replacement policy, and any hose near the shell showing cover damage regardless of age.AAnnual or outage · Mechanical crew
Drain and clean the reservoir interior where oil analysis shows heavy contamination, and change oil by analysis trend and not calendar alone.AAnnual or outage · Lubrication crew
Overhaul or replace electrode servo and proportional valves per OEM guidance, and bench-test response where facilities allow.AAnnual or outage · Automation crew
Reseal or replace cylinders with confirmed drift, and inspect rods, bushings, pins and mounting brackets.AAnnual or outage · Mechanical crew
Inspect and clean cooler tubes or plates, and pressure test the exchanger per OEM guidance.AAnnual or outage · Utilities crew
Recalibrate pressure transmitters and gauges, verify relief and protection setpoints, and test all hydraulic alarms and trips.AAnnual or outage · Automation crew
10Inspection Sign-Off and Records
Every failed or marginal item has a work order number recorded against the correct asset.EEach route · Inspector
Photos are attached for leaks, hose damage and rod scoring so condition can be compared on later routes.EEach route · Inspector
Pressure, temperature and drift readings are entered as numbers and not as a simple pass mark.EEach route · Inspector
Oil sample dates, filter changes and top-up volumes are updated against the asset history.EEach route · Lubrication technician
The supervisor has reviewed the completed route, accepted or escalated each finding, and signed off.EEach route · Maintenance supervisor
Turn the Checklist Into a Route Your Crew Completes
Load these inspection groups into Oxmaint as mobile routes with numeric fields, photos and automatic work orders for failed items, so every furnace circuit has a traceable condition record.
Where Hydraulics Work on an Electric Arc Furnace
Furnace designs differ, but most EAF bays rely on hydraulics for the circuits below. Each one fails in its own way and costs the melt shop differently.
| Circuit | Function | What a failure looks like |
|---|---|---|
| Electrode regulation | Positions electrode arms to hold arc length through fast valve response | Hunting, electrode breakage, unstable power input |
| Roof lift and swing | Raises and moves the roof for scrap charging | Slow or uneven lift, cylinder drift, charging delays |
| Furnace tilt | Tilts the shell for tapping and deslagging | Jerky motion, pressure spikes, leaks near hot zones |
| Slag door and tapping gear | Operates the door, taphole or EBT mechanisms | Door stuck, missed or slow taps, spray near the shell |
| Power unit and cooling | Supplies filtered, temperature-controlled oil to every circuit | Overheating, cavitation, filters running in bypass |
Symptoms Operators Report and Where to Look First
Operators rarely say "servo valve contamination". They describe behaviour. This map links common complaints to the first inspection point.
Operator reportsElectrodes keep hunting and tips break more often
Inspect firstServo and proportional valve filters, oil cleanliness, null drift, position sensor signal and cable condition
Operator reportsRoof settles slowly while held over the shell
Inspect firstPiston seals, counterbalance or holding valves, and external leak paths at the cylinder
Operator reportsTilt motion is slow near the end of tapping
Inspect firstPump output under peak demand, accumulator precharge and relief valve setting
Operator reportsHydraulic oil temperature climbs through the shift
Inspect firstCooler fouling, cooling water flow, internal leakage and pump case drain
Operator reportsOil film or drips under the platform
Inspect firstHose covers, fittings near the shell, rod seals and manifold sub-plates
Root Causes Behind Most EAF Hydraulic Failures
Most failures trace back to a short list of conditions that are all detectable with disciplined routine checks.
1
Particle and water contaminationScrap-bay dust, open fill points and failed breathers feed abrasive particles into servo valves and pump clearances. Water ingress from cooler leaks or condensation degrades oil and accelerates wear.
2
Heat and radiationHoses, seals and solenoid coils near the shell harden, crack or lose insulation faster than equipment in a normal plant. Heat shields that are removed and not refitted shorten life further.
3
Oil temperature and cooling lossA fouled water-oil cooler or a restricted cooling circuit pushes oil above its design band, thinning the fluid, shrinking film strength and ageing seals.
4
Pressure shocks and cyclingFast direction changes, failed accumulators and mis-set relief valves create spikes that fatigue fittings, rod ends and pipe supports.
5
Fluid selection and mixingFire-resistant fluids such as water-glycol, synthetic ester and phosphate ester differ in seal compatibility and care needs. Topping up with the wrong fluid causes seal swelling or premature breakdown.
6
Reactive maintenance habitsFilters changed only when alarms trigger, leaks logged on paper and never trended, and inspection findings that never become work orders all let small defects mature into stoppages.
Reading Pressure, Temperature and Flow Trends
A single reading says little. The pattern across shifts is what supports EAF predictive maintenance and condition-based decisions.
| Signal | Healthy pattern | Warning pattern | Likely causes | Action |
|---|---|---|---|---|
| Standby system pressure | Stable at setpoint | Slow sag or saw-tooth | Compensator wear, relief leakage, lost precharge | Check relief, accumulators and pump control |
| Pressure dip during roof swing | Brief, controlled dip | Deeper dip, slow recovery | Pump wear, suction restriction, weak accumulator | Review pump drain and suction line |
| Electrode circuit ripple | Consistent and low | Growing oscillation | Valve contamination, air in oil, sensor noise | Sample oil, inspect valve filters and feedback |
| Filter differential pressure | Gradual rise, resets after change | Fast rise after change, or bypass | Heavy ingression, fluid breakdown | Find contamination source, sample oil |
| Oil temperature | Steady at similar duty | Upward drift over weeks | Cooler fouling, internal leakage | Inspect cooler and case drain flow |
| Cylinder drift rate | Within acceptance limit | Increasing test over test | Piston seal bypass, holding valve leak | Plan seal or valve work at next outage |
Escalation Criteria: When a Finding Becomes a Stop
Clear thresholds stop the same leak being debated every shift. Set exact limits with your OEM and safety team, then apply them consistently.
Level 1 · Observe and logLight seal film, small oil temperature drift, filter indicator rising normally. Record, photograph and trend.
Level 2 · Plan corrective workVisible drip, growing cylinder drift, repeated valve hunting. Raise a work order and reserve parts for the next planned stop.
Level 3 · Fix at next available furnace stopFilter in bypass, accumulator precharge loss, cooling shortfall, hose with blistered cover. Do not wait for the full outage.
Level 4 · Stop and isolateSpray or pooling oil near hot surfaces, burst or leaking hose on an energized circuit, cracked rod or mount. Stop the equipment and follow lockout procedures.
How the Inspection Workflow Runs in Oxmaint
A checklist only improves reliability when findings become tracked work. This sequence connects the floor to the maintenance plan.
1
Build the asset hierarchyStructure furnace, power unit, valve stand, cylinders and accumulators as linked assets so history stays with the right component.
2
Assign mobile inspection routesOperators and technicians complete shift, weekly and monthly checks on a phone with pressure, temperature and drift entered as numbers.
3
Trigger corrective work ordersA failed or out-of-range item opens a work order with priority, photos and the responsible crew.
4
Link spares and filter inventorySeal kits, hoses, filter elements and servo valves are reserved against the job so repairs are not delayed by missing parts.
5
Schedule preventive tasksFilter changes, oil sampling and precharge checks recur on time or meter basis, with overdue tasks visible to supervisors.
6
Review dashboards and historyRepeat failures, leak trends and completion rates guide outage scope and spare parts decisions across the steel plant.
KPIs That Show Whether EAF Hydraulics Are Under Control
Track a small set of measures that connect inspection discipline to furnace availability.
| Metric | How to calculate | Desired direction |
|---|---|---|
| Hydraulic delay minutes | Furnace delay time coded to hydraulic causes per month | Falling |
| Inspection route completion | Completed hydraulic routes divided by scheduled routes | Near 100% |
| Leak work order closure | Leak orders closed within target time divided by all leak orders | Rising |
| Oil analysis in target | Samples inside cleanliness and water limits divided by samples taken | Rising |
| Overdue filter tasks | Filter changes past due date at month end | Zero |
| Repeat failures | Same component failing again within a set period | Falling |
| Hose age compliance | Hoses within replacement policy divided by hoses tracked | Rising |
